Main Technical Parameters
| Vehicle Description | Brand | CLW |
| GVW(kg) | 9780 | |
| Curb Weight(kg) | 4780 | |
| Overall Dimension(mm) | 7450*2300*2300 | |
| Wheelbase(mm) | 3815 | |
| Axle Load(kg) | 3000/5000 | |
| Top Speed(km/h) | 95 | |
| Chassis Brand | I-Su-Zu | |
| Chassis Model | QL1110ANMAY | |
| Cabin | Single,LHD,with A/C | |
| Engine | Model | 4KH1CN6LB |
| HP | 120 | |
| Emission Standard | Euro 6 | |
| Displacement/Output(ml/kw) | 2999/88 | |
| Fuel Type | Diesel | |
| Rate Speed(rpm) | 2900 | |
| Maximum Torque(N·m) | 290 | |
| Maximum Torque Speed(rpm) | 1500-2900 | |
| Gearbox | 5Forward/1Reverse Gear | |
| Tyre | 7.50R16LT 14PR | |
| Platform Configuration | L*W(mm) | 5400*2300 |
| Operating Stroke(mm) | 2680 | |
| Min.Angle of Slope(°) | 8 | |
| Rated Loading Weight(kg) | 3000 | |
| Rated Winch Traction Weight(kg) | 3500 | |
| Length Of Steel Wire Rope(m) | 21 | |
| Ground Clearance Of Cage Floor | 470 | |
| Hoisting Organ | Maximum Length Of Extended Boom(mm) | 1300 |
| Rated Lifting Weight(kg) | 2500 | |
| Maximum Extended Lifting Weight(kg) | 1250 | |
| Rated Traction Weight(kg) | 7100 | |
| Elevation Of Boom(upper/lower) | 9°~-10° | |
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
