Product Description:


1. This vehicle is a dangerous goods vehicle. The type of dangerous goods transport vehicle is FL. The total tank capacity is 21.0 cubic meters, and the effective tank volume is 20 cubic meters.

2. The maximum density (kg/cubic meter) of the permitted medium is 700. The tank dimensions (length × long axis × short axis) (mm) are: 7000×2480×1750, 7000×2350×1620.

3. The side and rear protections are both connected to the girder by bolts made of Q235 material. The cross-sectional dimension of the rear protection device (mm) is: 140×50. The ground clearance of the rear protection is 440mm.

4. Only radial tires are selected. A speed-limiting device is installed with a speed limit of 80km/h. The exhaust pipe is located in the front. The front wheels are equipped with disc brakes. A driving recorder with satellite positioning function is installed. The rear axle is equipped with an air suspension. The steering wheels are equipped with a tire blowout emergency protection device.

5. Optional fender styles. Optional pump box and toolbox with different lock appearances. Optional rear ladder styles. Optional safety notice board styles on the right side of the rear and on both sides of the vehicle body. Optional rear clearance light bracket styles. Optional tank walkway styles. Optional cab and vehicle body side appearance according to the chassis.



Main Technical Parameters


vehicle DescriptionBrandCLW
GVW(kg)26000
Curb Weight(kg)11805
Loading Weight(kg)14000
Overall Dimension(mm)9800x2550x3500
Wheelbase(mm)4125+1350
Axle Load(kg)7000/19000
Top Speed(km/h)80

Chassis BrandDONGFENG
Chassis ModelDFH1260D
CabinSingle,LHD,with A/C
EngineModelWP10.340E32
Hp340
Emission StandardEuro 3
Displacement/Output(ml/kw)9725/250
Fuel TypeDiesel
Rate Speed(rpm)2200
Maximum Torque(N·m)1250
Maximum Torque Speed(rpm)1400-1600
Gearbox BrandFast
Gearbox10Forward/2Reverse Gear
Tyre295/80R22.5 18PR

Fuel TankCapacity(cbm)20/22/24/25
Tank MaterialCarbon steel Q235
Compartment Quantity(pcs)`1/2
Filling MediumGasoline,Diesel Or Other Loading Medium
thickness(mm)Head is 5mm; tank is 5mm ;separated plate is 5mm;breakwater plate is 4mm
Compartments9
Manhole1. Two manholes with a diameter of 20 inches and 20-inch manhole covers; a 10-inch filling/venting port. The pressure vacuum vent and emergency vent are included in the manhole assembly.
2. Protective covers are provided for the manholes.
Discharge systemBottom loading and gravity discharge system:
1. Bottom valve: There are 2*4-inch pneumatic bottom valves at the bottom of the tanker.
2. 4-inch aluminum alloy pipeline
3. There are 2*4-inch API adapters on the right side of the tanker, equipped with aluminum dust covers. Horizontal installation.
4. All outlets are inside the aluminum alloy box.
5. The outlet box is equipped with a collapsible door with a lock.
Vapor Recovery System1. Two sequential pneumatically controlled air vents.
2. A 3-inch aluminum alloy pipeline from the two manholes to the middle bottom of the tank.
3. One vapor recovery adapter is installed on the right side of the middle bottom of the tank.
