Technical Specifications of the CLW 3cbm Milk Tank Truck：
| Vehicle Description | Brand | CLW |
| GVW(kg) | 4495 | |
| Curb Weight(kg) | 2380 | |
| Overall Dimension(mm) | 5160*1900*2090 | |
| Wheelbase(mm) | 2930 | |
| Axle Load(kg) | 1700/2795 | |
| Top Speed(km/h) | 89 | |
| Chassis Model | SC5021XXYVQ6B1 | |
| Cabin | Single,LHD,with A/C | |
| Engine | Model | CY4102-C3D |
| HP | 109 | |
| Emission Standard | Euro 3 | |
| Displacement/Output(ml/kw) | 3856/80 | |
| Fuel Type | Diesel | |
| Rate Speed(rpm) | 2800 | |
| Maximum Torque(N·m) | 300 | |
| Maximum Torque Speed(rpm) | 1400-1800 | |
| Gearbox | 6Forward/1Reverse Gear | |
| Tyre | 185R15LT 8PR | |
| Fuel Tank | tank Capacity | 1.4000 liters to 10000 liters |
| 2.12000liters to 20000 liters | ||
| Tank shape | Oval shape | |
| Fuel tanker size | 3500x1800x1350 | |
| 5500x2000x1450 | ||
| Tank material | Mild steel/Stainless steel/Aluminium alloy | |
| Standard equipment | With oil pump, oil loading and discharging system. Equipment opting China standard or EURO or US standard..The tank could be separated several compartment. | |
| Also could modify in refuel or transport fuel tank truck. | ||
Product Description：
The thickness of the external insulation layer of the tank body is 120mm. The materials of the side and rear protections are all Q235. The side and rear protections are connected to the vehicle body by bolts. The cross-sectional dimensions (height × width) of the rear lower protection are 100mm × 50mm, and the ground clearance is 380mm. Optional new grille and new front combination lamps are available according to the chassis. Optional side door logo. Optional front grille and LOGO sign. The vehicle in ready condition is equipped with: spare tire, standard spare parts, coolant, and cleaning fluid.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
