Main Technology Parameter
| Vehicle Description | Brand | CLW |
| GVW(kg) | 18000 | |
| Curb Weight(kg) | 11000 | |
| Overall Dimension(mm) | 8550*2480*3110 | |
| Maximum height of suction cup off the ground(mm) | 220 | |
| Front Axle(mm) | 1430 | |
| Rear Axle(mm) | 2120 | |
| Top Speed(km/h) | 89 | |
| Chassis Description | Chassis Brand | Howo |
| Chassis Model | ZZ1187K501GF1 | |
| Wheelbase(mm) | 5000 | |
| Traction Type | 4X2 | |
| Engine Brand | Weichai | |
| Engine Model | WP4.6NQ240E62 | |
| Emission Level | Eu 3/Eu 6 | |
| Displacement/Output(ml/kw) | 4600/177 | |
| Horsepower | 240 | |
| Fuel Type | Diesel | |
| High-Pressure Cleaning | Water Pressure(Mpa) | 10 |
| Water Pump Flow(L/min) | 142 | |
| Suction Sweep Operation | Cleaning Efficiency | ≥95 |
| Maximum Suction Particle Size(mm) | 110 | |
| Operating Width(mm) | 3500 | |
| Maximum Cleaning Capacity(m³/h) | 52500 | |
| Sweep Tray Overhanging Dimensions(mm) | ≥400 | |
| Operating Speed(km/h) | 3-15 | |
| Water Tank | Water Tank Volume(m³) | 9 |
| Dust Bin | Dust Tank Volume(m³) | 7 |
| Dump Bin Tilting Angle | ≥50 | |
| Hydraulic System | Type | Open Circuit Hydraulic,Electrical Control |
| System Pressure(Mpa) | 16 | |
| Hydraulic Tank Capacity(L) | 60 | |
| High-Pressure Water System | Type | Piston Pump |
| Brand-Model | Pinfl-PT40 | |
| System Pressure(Mpa) | 10 | |
| Rotaional Speed(r/min) | 1450 | |
| Water Valve Type | High-Pressure Pneumatic Ball Valve | |
Working Effects
Washing of Curb and Vertical Surface of Curb Stones
This sweeper is equipped with the function of washing the curb and the vertical surface of curb stones. It can conduct comprehensive and meticulous cleaning on the edges of the road and the vertical surfaces of curb stones. Through the specialized washing device, it can effectively remove the accumulated dirt and dust in these areas, restoring the cleanliness of the road edges and curb stones and enhancing the overall cleanliness of the road.
Dust Suppression by Rear Spray
The dust suppression function by rear spray plays an important role during the vehicle's driving. By spraying fine water mist to the rear, it can effectively reduce the dust content in the air, decrease dust pollution, and improve the surrounding air quality. The effect is more remarkable especially in dry and dusty environments.
Low-Pressure Flushing
The low-pressure flushing function can use water flow with lower pressure to conduct gentle flushing on the road surface. It can remove the loose dirt and debris on the road surface and prepare for the subsequent high-pressure cleaning. This low-pressure flushing method can achieve the cleaning purpose without causing excessive impact and damage to the road surface.
High-Pressure Cleaning
High-pressure cleaning is one of the core functions of this vehicle. With the powerful pressure water flow, it can deeply clean the stubborn stains and oil stains on the road surface, completely remove them, and restore the road surface to its original state. Whether it is asphalt pavement or cement pavement, it can achieve efficient cleaning.
Fixed-Point Flushing Device in Front of the Vehicle
The fixed-point flushing device in front of the vehicle can conduct accurate fixed-point flushing on specific areas as needed. For example, for some hard-to-clean corners on the road, oil stain accumulation points, or stains near traffic signs, this device can play an important role in conducting targeted cleaning and improving the cleaning effect.
Self-Cleaning Function of the Garbage Bin
The self-cleaning function of the garbage bin provides great convenience for the vehicle's maintenance and hygiene keeping. After completing the garbage collection task, through specific cleaning procedures, it can conduct automatic cleaning inside the garbage bin, remove the residual garbage and dirt, prevent the generation of odors and the breeding of bacteria, maintain the cleanliness and hygiene of the garbage bin, and prolong the service life of the garbage bin.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
