Main Technical Parameters：
| Main Technical Parameter | |
| Model Name | CLW DongFeng sewage suction truck |
| Driving Type | 4x2 |
| Cabin | DongFeng DFAC |
| Color | White |
| Weight | |
| Rated Payload Weight（kg） | 2430 |
| Curb Weight(kg) | 4800 |
| GVW(kg) | 7360 |
| Dimensions | |
| Wheelbase(mm) | 3308 |
| Overall Dimension(mm) | 5995x2090x2520 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | B125 33 |
| Engine Type | Four-stroke,Pressurized intercooler |
| No. of Cylinders | straight-4 cylinders, diesel |
| Displacement(L) | 3.9L |
| Max.Output(KW) | 92kw(125hp) |
| Drive Line | |
| Transmission | FAST:5J38TA,5 forwards,1 reverse gear,manual operation |
| Steering | Power steering |
| Brake | Oil brake with vacuum pump |
| Axle | |
| Front Axle | 4.35 tons(MAN technology) |
| Rear Axle | 7.645 tons(MAN Technology) |
| Tire Specification | |
| Tire Specification | 245/70R19.5;Standard tire;6 tires+1 spare tire |
| Sewage Suction Tank | |
| Sewage Tank Volume | 2.95m³ |
| Water Tank Volume | 2.36m³ |
| Tank material | 4mm thickness,Q235A |
| Water Tank Material | 4mm thickness,Q235A |
| Pump | Weilong double pump 65QZDH-110/7000, Power rate :12KW; Pumping speed: 110L/S; Absolute pressure:7000Pa;Suction depth: 7 meters, |
| Other key parts | Power-take-off, hydraulic cylinders, multi-way valve , pressure gauges, water-gas separator , oil-gas separator, level inspection window, suction hose |
Product Description:
1. The special device of this vehicle is a tank body and a cleaning and suction device, which is mainly used for sewer drainage and dredging. It is modified with a chassis with a wheelbase of 3308mm. The total capacity of the sewage tank is 3.09 cubic meters, and the effective volume is 2.95 cubic meters. The medium is liquid dirt with a density of 800 kilograms per cubic meter. The total length of the tank body including the head (mm): 3350. The straight section length × diameter (mm): 3100 × 1200. The total capacity of the clean water tank is 2.48 cubic meters, and the effective volume is 2.36 cubic meters. The medium is water with a density of 1000 kilograms per cubic meter. The tank body is a special-shaped tank. The size of the special-shaped tank (mm) is: length × width × height = 2950 × 550 × 800 (mm). The two tanks are independent and cannot be fully loaded at the same time. When cleaning, use the clean water tank. When suctioning sewage, use the sewage tank. The tank body can be lifted.
2. The side protection material and the rear protection are both made of Q235A material. The left and right side protections are connected by bolts, and the rear protection is connected by welding. The cross-sectional size of the rear protection (mm): 100 × 50. The ground clearance of the rear protection (mm): 340.
3. Optional installation positions of water pumps and rear appearance styles. Optional tank styles. Optional cabs according to the chassis.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
