Main Technical Parameters：
| Main Technology Parameter | |
| Model Name | CLW Brand Shacman X3000 6x4 Sewage Suction Truck |
| Driving Type | 6x4 |
| Color | Red and orange or based on client’s request. |
| Number of Cabs | 2 |
| Weights | |
| GVW(kg) | 25000 |
| Rated Payload Weight(kg) | 11070 |
| Curb Weight(kg) | 13800 |
| Dimensions | |
| Wheelbase(mm) | 4375+1400 |
| Front/Rear Overhang(mm) | 1525/1850 |
| Approach/Departure Angle | 16/14 |
| Overall Dimension(mm) | 9150x2550x3650 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | WP10.340E32 |
| Engine Type | Water-cooled,four-stroke,with exhaust valve braking, direct injection turbocharged with intercooling |
| Max.Output(kw) | 250(340hp) |
| Drive Line | |
| Transmission | 10 forwards,2 reverse gear,10JSD180 |
| Axle | |
| Axle | 7000/18000 |
| Tire Specification | |
| Tire Specification | 11.00R20 18PR; 10+1 spare tire |
| Front Wheel Track(mm) | 2036 |
| Rear Wheel Track(mm) | 1860/1860 |
| Number of Leaf Springs | 10/12 |
| Upper Body | |
| Van Box Size(mm) | 5650x1900 |
| Box Material | Carbon Steel,Stainless Steel,According to Customer needs |
| Sewage Tank Volume | 13.82m³ |
| SewageTank Material | 5mm thickness;Q235A |
| Pump | Weilong double pump 65QZDH-110/7000, Power rate :12KW; Pumping speed: 110L/S; Absolute pressure:7000Pa;Suction depth: 7 meters, |
| Other Key Parts | Power-take-off, hydraulic cylinders, multi-way valve , pressure gauges, water-gas separator , oil-gas separator, level inspection window, suction hose |
Product Description：
1. The special devices mainly consist of tanks, pumps and pipeline systems, which are used for the suction operation of liquid waste.
2. The total capacity of the tank is 14.52 cubic meters, and the effective volume of the tank is 13.82 cubic meters. The medium is liquid waste, and the density is 800 kilograms per cubic meter.
3. The external dimensions of the tank (length × diameter) (in millimeters) are 5650 (including the straight section length of 5050) × 1900.
4. The materials for the side and rear guards are Q235, and the connection methods are all welding connections. The cross-sectional dimension of the rear guard is 200 mm × 50 mm, and the height from the ground is 460 mm.
5. Cab pictures can be selected according to the chassis. Pictures of the exterior on both sides of the vehicle body and the rear exterior can be selected. Different layout styles of the rear processors, fuel tanks, batteries, air reservoirs and urea tanks on both sides of the vehicle body can be selected according to the chassis.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
