Main Technical Parameters：
| Main Technical Parameter | |
| Model Name | CLW HOWO sewage suction truck |
| Driving Type | 4x2 |
| Cabin | HOWO |
| Color | White |
| Weight | |
| Rated Payload Weight（kg） | 6570 |
| Curb Weight(kg) | 9030 |
| GVW(kg) | 16000 |
| Dimensions | |
| Wheelbase(mm) | 4000 |
| Overall Dimension(mm) | 8150x2450x3390 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | B190 33 |
| Engine Type | Four-stroke,Pressurized intercooler |
| No. of Cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 5.9L |
| Max.Output(KW) | 140kw(190hp) |
| Drive Line | |
| Transmission | 8 forwards,1 reverse gear,manual operation |
| Steering | Power steering |
| Brake | Oil brake with vacuum pump |
| Axle | |
| Front Axle | 5.6 tons(MAN technology) |
| Rear Axle | 10.195 tons(MAN Technology) |
| Tire Specification | |
| Tire Specification | 275/80R22.5 18PR;Standard tire;6 tires+1 spare tire |
| Sewage Suction Tank | |
| Sewage Tank Volume | 7.96m³ |
| Water Tank Volume | 3.4m³ |
| Tank material | 5mm thickness,Q235A |
| Water Tank Material | 5mm thickness,Q235A |
| Pump | Weilong double pump 65QZDH-110/7000, Power rate :12KW; Pumping speed: 110L/S; Absolute pressure:7000Pa;Suction depth: 7 meters, |
| Other key parts | Power-take-off, hydraulic cylinders, multi-way valve , pressure gauges, water-gas separator , oil-gas separator, level inspection window, suction hose |
Product Description:
1. This vehicle is used for sewer dredging, cleaning, and sewage suction and has a lifting function. The main special devices are: tank body, sewage suction pump, and cleaning and scouring assembly.
2. Tank body dimensions: total length × diameter (mm): 5200×1850. The front section of the tank body is a clean water tank (length 1700mm); the rear section is a sewage tank (length 3500mm). The two tanks are independent and cannot be fully loaded at the same time. The clean water tank is used for cleaning functions, and the sewage tank is used for sewage suction functions. The two tanks cannot be used simultaneously. The total capacity of the clean water tank is 3.5 cubic meters, and the effective volume of the clean water tank is 3.4 cubic meters. The medium is water, and the density is 1000 kilograms/cubic meter. The total capacity of the sewage tank is 8.35 cubic meters, and the effective volume of the sewage tank is 7.96 cubic meters. The medium is liquid waste, and the density is 800 kilograms/cubic meter.
3. The side and rear protection materials are both Q235. The connection methods are all welding. The rear protection cross-sectional dimension is 120×60mm. The lower edge is 450mm above the ground. The rear operation lamps are only turned on when the vehicle is parked for operation and cannot be turned on during driving.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
