| Main Technology Parameter | |
| Model Name | CLW Brand HOWO 6x4 Van Body Truck |
| Driving Type | 6x4 |
| Color | white or based on client’s request. |
| Number of Cabs | 3 |
| Weights | |
| GVW(kg) | 25000 |
| Rated Payload Weight(kg) | 10150 |
| Curb Weight(kg) | 14720 |
| Dimensions | |
| Wheelbase(mm) | 3900+1350 |
| Front/Rear Overhang(mm) | 1450/2620 |
| Approach/Departure Angle | 16/11 |
| Overall Dimension(mm) | 9320x2550x3650 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | WP10.340E32 |
| Engine Type | Water-cooled,four-stroke,with exhaust valve braking, direct injection turbocharged with intercooling |
| Rated Torque(Nm) | 1250 |
| Rated Speed(rpm) | 2200 |
| Max.Output(kw) | 250(340hp) |
| Drive Line | |
| Transmission | 10 forwards,2 reverse gear,10JSD180 |
| Axle | |
| Axle | 7000/18000/18000 |
| Tire Specification | |
| Tire Specification | 295/80R22.5 18PR; 10+1 spare tire |
| Front Wheel Track(mm) | 1998 |
| Rear Wheel Track(mm) | 1850/1850 |
| Number of Leaf Springs | 3/2+-/2+- |
| Upper Body | |
| Van Box Size(mm) | 6400x5800x2000 |
| Box Material | Carbon Steel,Stainless Steel,According to Customer needs |
| Sewage Tank Volume | 12.68m³ |
| Water Tank Volume | 4.78m³ |
| SewageTank Material | 5mm thickness;Q235A |
| Water Tank Material | 5mm thickness;Q235A |
| Pump | Weilong double pump 65QZDH-110/7000, Power rate :12KW; Pumping speed: 110L/S; Absolute pressure:7000Pa;Suction depth: 7 meters, |
| Other Key Parts | Power-take-off, hydraulic cylinders, multi-way valve , pressure gauges, water-gas separator , oil-gas separator, level inspection window, suction hose |
The special devices of this vehicle are the tank body and the cleaning and sewage suction devices. It is mainly used for sewer drainage and dredging, and the tank body can be lifted for operation.
Dimension of the tank body (total length x straight section length x diameter)(mm): 6400x5800x2000. The front section of the tank body is the clean water tank with a straight section length of 1600 mm. The total capacity of the clean water tank is 5.02 cbm, the effective volume is 4.78 cbm, the medium is water, and the density is 1000 kg/m³. The rear section is the sewage tank with a straight section length of 4200 mm. The total capacity of the sewage tank is 13.32 cbm, the effective volume is 12.68 cbm, the medium is liquid waste, and the density is 800 kg/m³. The two tanks are independent and cannot be fully loaded at the same time. The clean water tank is used for the cleaning function, and the sewage tank is used for the sewage suction function.
The materials of the side and rear protective devices are all Q235A. Connection method: The left and right side protective devices and the rear lower protective are all connected by welding. The cross-sectional dimensions(width x height) of the rear protective device are 310x50 mm, and the height from the lower edge to the ground is 500 mm.
The speed-limiting device can be optionally installed with the chassis, with speed limits of 80 km/h and 89 km/h. Only the chassis leaf spring suspension and 11.00R20 and 295/80R22.5 tires are used.
The corresponding relationships of the overall vehicle length/front overhang/wheelbase/rear overhang are(mm): 9320/1450/3900+1350/2620.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
