Technical Specifications of the CLW 12cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand Shacman L3000 4x2 12cbm Garbage Compactor truck |
| Driving Type | 4x2 |
| Color | White color or based on client’s request. |
| Weights | |
| GVW(kg) | 18000 |
| Rated payload weight(kg) | 7185 |
| Curb weight(kg) | 10620 |
| Dimensions | |
| Wheelbase(mm) | 4700 |
| Overall Dimension(mm) | 8830x2500x3300 |
| Max speed(km/h) | 89 |
| Engine | |
| Engine model | B210 33 |
| Emission standard | Euro 3 |
| Engine type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 5.9 |
| Max. output (kw) | 155(210hp) |
| Drive Line | |
| Transmission | Fast Brand;8 forwards,2 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Air brake with vacuum pump |
| Axle | |
| Front axle | Dena 6.5 tons |
| Rear axle | Dena 11 tons |
| Tire specification | |
| Tire specification | 10.00R20 18PR |
| Garbage compactor box | |
| Volume | 12 cbm |
| Raw material | T700L, side is 4mm, and bottom is 5mm. |
| Loading Method | Rear loader, waste bins flipover mechanism, can match 2 units 240 L, or 1 unit 180L and 1 unit 300L waste bins |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
The main special devices of this vehicle consist of a box body, a packer assembly, a compression system, etc., and are used for the collection and transportation of garbage. Optional rear working devices.
The corresponding relationship between the overall vehicle length and rear overhang (mm) is as follows: ①Without a loading device: 8830/-; ②With a fully sealed bucket device and a swing arm device: 9030/200; ③With a flip bucket device and a dump device: 9230/400. Only a wheelbase of 4700mm is used.
The side protection material is Q235 and is connected by bolts. The rear protection is replaced by special devices. The height from the lower edge to the ground is 460mm. Optional cabs along with the chassis, optional front bumper appearance, optional sun visor appearance, optional fender appearance, and optional cab side door appearance. Optional arc-shaped mudguards. Optional rear lighting. The rear lighting is only used in the working state and cannot be lit during driving. Optional rear deflector structure. Optional flip frame style.
