Technical Specifications of the CLW ISUZU 8cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand dongfeng 4x2 8cbm Garbage Compactor truck |
| Driving Type | 4x2 |
| Color | White color or based on client’s request. |
| Number of Cabs | 2 |
| Weights | |
| GVW(kg) | 7360 |
| Rated Payload Weight(kg) | 1730 |
| Curb Weight(kg) | 5500 |
| Dimensions | |
| Wheelbase(mm) | 3308 |
| Front/Rear Overhang(mm) | 1055/2037 |
| Approach/Departure Angle | 27.7/12 |
| Overall Dimension(mm) | 6600x2050x2620 |
| Max Speed(km/h) | 90 |
| Engine | |
| Engine Model | ISD140 50 |
| Emission Standard | Euro 3 |
| Engine Type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of Cylinders | straight-4 cylinders, diesel |
| Displacement(L) | 4.5 |
| Max. Output (kw) | 132(140hp) |
| Drive Line | |
| Transmission | 5 forwards,1 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Air brake with vacuum pump |
| Axle | |
| Front Axle | Dena 2.64 tons |
| Rear Axle | Dena 4.72 tons |
| Tire Specification | |
| Tire Specification | 7.50R16LT 16PR |
| Front Wheel Track(mm) | 1519 |
| Rear Wheel Track(mm) | 1516 |
| Number of Leaf Springs | 6/6+5 |
| Garbage Compactor Box | |
| Volume | 8 cbm |
| Raw Material | Q235, side is 4mm, and bottom is 5mm. |
| Loading Method | 1.Optional rear-mounted bucker tipping mechanism(120L,240L,360L,660L nad 1100L) 2.Optional garbage hopper tipping mechanism |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
This vehicle is mainly used for the compression and transfer of domestic waste. The special device is a waste compression device.
When equipped with a flipping bucket device, its overall length is 6800mm with a rear extension of 400mm, and the curb weight is 5700kg. When equipped with a bucket device, its overall length is 6600mm with a rear extension of 200mm, and the curb weight is 5500kg.
Side protection material: aluminum alloy. Connection method: bolt connection. The rear protection is replaced by a special device. The ground clearance is 350mm.
Optional rear lamps. Oprional license plate installation position for flipping bucket types.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
