Technical Specifications of the CLW ISUZU 8cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand FAW 4x2 Garbage Compactor Truck |
| Driving Type | 4x2 |
| Color | white or based on client’s request. |
| Number of Cabs | 2 |
| Weights | |
| GVW(kg) | 9100 |
| Curb Weight(kg) | 5950 |
| Dimensions | |
| Wheelbase(mm) | 3300 |
| Front/Rear Overhang(mm) | 1155/2115 |
| Approach/Departure Angle | 20/13 |
| Overall Dimension(mm) | 6570x2100x2550 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | D25TCIF1 |
| Engine Type | Turbocharged with inter-cooler, In-line six-cylinder |
| Rated Torque(Nm) | 400 |
| Max.Output(kw) | 110(150hp) |
| Drive Line | |
| Transmission | 5 forwards,1 reverse gear |
| Steering | Power steering |
| Brake | Air brake system |
| Axle | |
| Axle | 3300/5800 |
| Tire Specification | |
| Tire Specification | 7.50R16LT 16PR; 6+1spare tire |
| Front Wheel Track(mm) | 1726 |
| Rear Wheel Track(mm) | 1687 |
| Upper Body Configuration | |
| Volume | 6cbm |
| Raw Material | Q235, side is 4mm, bottom is 4mm |
| Loading Method | 1.Optional rear-mounted bucker tipping mechanism(120L,240L,660L) 2.Optional garbage hopper tipping mechanism |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
1. This vehicle is equipped with a garbage bin, a hydraulic mechanism and a rear loading device, which are used for garbage collection, treatment and transfer operations.
2. Cabins of the same series can be optionally installed along with the chassis. The exterior with words pasted on the front can be optionally selected. The periphery and side patterns of the cabin can be optionally selected. The appearance of the front face can be optionally selected. The appearance of the rearview mirrors and mirror poles can be optionally selected. The appearance of the steps can be optionally selected. The appearance of the logos can be optionally selected. The front grille can be optionally selected. The appearance of the front bumper can be optionally selected. The appearance of the wheel rims and the appearance of the storage battery can be optionally selected. The front ladder on the right side of the box body can be optionally selected.
3. The protective materials of this vehicle are all made of Q235. The side protective parts are connected by bolts. The rear protective part is replaced by a special working device, and its height from the ground is 480mm.
4. The appearance of the box body and the rear appearance of the special device can be optionally selected.
