Technical Specifications of the CLW E 13cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand E 13cbm garbage compactor Truck |
| Driving Type | 4x2 |
| Color | white and blue or based on client’s request. |
| Number of Cabs | 3 |
| Weights | |
| GVW(kg) | 18000 |
| Rated Payload Weight(kg) | 11500 |
| Curb Weight(kg) | 6370 |
| Dimensions | |
| Wheelbase(mm) | 4500 |
| Front/Rear Overhang(mm) | 1490/2795 |
| Approach/Departure Angle | 16/13 |
| Overall Dimension(mm) | 9045x2550x3200 |
| Max Speed(km/h) | 90 |
| Engine | |
| Engine Model | TZ366XS50E |
| Emission Standard | / |
| Engine Type | Permanent magnet synchronous motor |
| Max.Output(kw) | 120/200(272hp) |
| Drive Line | |
| Transmission | 4 forwards,1 reverse gear,AMT |
| Steering | Power steering |
| Brake | Air brake system(front and rear drum brakes) |
| Axle | |
| Front Axle | Dena 6.5 tons |
| Rear Axle | Dena 11.5tons |
| Tire Specification | |
| Tire Specification | 295/80R22.5 18PR |
| Front Wheel Track(mm) | 2016 |
| Rear Wheel Track(mm) | 1868 |
| Number of Leaf Springs | 8/10+7,3/4+3 |
| Garbage Compactor Box | |
| Volume | 13m³ |
| Raw Material | Qste420tm(side 5mm, and bottom 5mm) |
| Power Take-off Method | Electric power take-off |
| Rated power of the mounted motor | 30/45kw |
| Sewage Tank | The filler:500L |
| side-mounted auxiliary sewage tank:450L | |
| Volume of the Filler | 1.8cbm |
| Abti-corrosion for Upper Body | All structural components are powder-coating in standard Glacier White. Powder coating in other colors requires customization |
| Loading Capacity | 9000kg |
| Number of Garbage Bins Loaded(bins) | Around 270 full 240L bins |
| Applicable Standard Garbage Bin Types | 120L,120L double,240L,240L double,660L |
| Operation | Central control screen(in the cab)+ operation panel |
Product Description:
Functional configurations: Skateboard, scraper, bucket-lifting mechanism, 660L arm, push plate, pneumatic filler port cover plate, side-mounted auxiliary sewage tank. Side protection: Patterned aluminum plate battery cover + aluminum alloy side protection. On-board operation: Central control screen in the cab + operation panel.
Other configurations: Airbag seat for the driver, four-way adjustable genuine leather seat, remote control central lock, electric window lift, multifunctional steering wheel with cruise control, 12.3-inch liquid crystal central control screen, 360-degree surround view function, integrated electric rearview mirror with heating function, single-cooling air conditioner + PTC (Positive Temperature Coefficient), rotary gear shift, EPB (Electronic Parking Brake) electronic parking brake, 12.3-inch full liquid crystal digital instrument panel, driving recorder, auto hold, tire pressure monitoring, ABS (Anti-lock Braking System), electro-hydraulic power assist, air brake system (front and rear drum brakes).
