Technical Specifications of the CLW ISUZU 8cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand Shacman 4x2 Garbage Compactor Truck |
| Driving Type | 4x2 |
| Color | white or based on client’s request. |
| Number of Cabs | 2 |
| Weights | |
| GVW(kg) | 8280 |
| Curb Weight(kg) | 6000 |
| Dimensions | |
| Wheelbase(mm) | 3600 |
| Front/Rear Overhang(mm) | 1165/2175 |
| Approach/Departure Angle | 18/11 |
| Overall Dimension(mm) | 7320x2250x2750 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | B170 33 |
| Engine Type | Turbocharged with inter-cooler, In-line six-cylinder |
| Rated Torque(Nm) | 560 |
| Max.Output(kw) | 125(170hp) |
| Drive Line | |
| Transmission | 5 forwards,1 reverse gear |
| Steering | Power steering |
| Brake | Air brake system |
| Axle | |
| Axle | 3000/5280 |
| Tire Specification | |
| Tire Specification | 7.50R16LT 14PR; 6+1spare tire |
| Front Wheel Track(mm) | 1650 |
| Rear Wheel Track(mm) | 1595 |
| Upper Body Configuration | |
| Volume | 10cbm |
| Raw Material | Q235, side is 4mm, bottom is 5mm |
| Loading Method | 1.Optional rear-mounted bucker tipping mechanism(120L,240L,360L,660L nad 1100L) 2.Optional garbage hopper tipping mechanism |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
1. This vehicle is equipped with a garbage bin, a hydraulic mechanism and a rear loading device, which are used for garbage collection, treatment and transfer operations.
2. This vehicle is configured with a hanging bucket type lifting mechanism, with a rear extension of 380mm and 400mm.
3. Cabins of the same series can be optionally installed along with the chassis. The exterior with words pasted on the front can be optionally selected. The periphery and side patterns of the cabin can be optionally selected. The appearance of the front face can be optionally selected. The appearance of the rearview mirrors and mirror poles can be optionally selected. The appearance of the steps can be optionally selected. The appearance of the logos can be optionally selected. The front grille can be optionally selected. The appearance of the front bumper can be optionally selected. The appearance of the wheel rims and the appearance of the storage battery can be optionally selected. The front ladder on the right side of the box body can be optionally selected.
4. The protective materials of this vehicle are all made of Q235. The side protective parts are connected by bolts. The rear protective part is replaced by a special working device, and its height from the ground is 480mm.
5. The appearance of the box body and the rear appearance of the special device can be optionally selected.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
