Technical Specifications of the CLW Shacman L3000 14cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand Shacman L3000 4x2 14cbm Garbage Compactor truck |
| Driving Type | 4x2 |
| Color | White color or based on client’s request. |
| Weights | |
| GVW(kg) | 18000 |
| Rated payload weight(kg) | 7185 |
| Curb weight(kg) | 10620 |
| Dimensions | |
| Wheelbase(mm) | 4700 |
| Overall Dimension(mm) | 8780*2550*3500 |
| Max speed(km/h) | 89 |
| Engine | |
| Engine model | WP6.270E32 |
| Emission standard | Euro 3 |
| Engine type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 6.75L |
| Max. output (kw) | 198(270hp) |
| Drive Line | |
| Transmission | Fast Brand;8 forwards,2 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Air brake with vacuum pump |
| Axle | |
| Front axle | Dena 6.5 tons |
| Rear axle | Dena 11 tons |
| Tire specification | |
| Tire specification | 10.00R20 18PR |
| Garbage compactor box | |
| Volume | 14 cbm |
| Raw material | T700L, side is 5mm, and bottom is 6mm. |
| Loading Method | Rear loader, waste bins flipover mechanism, can match 2 units 240 L, or 1 unit 180L and 1 unit 300L waste bins |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
1. The main special devices of this vehicle are composed of a box body and a compression system, and are used for the collection and transportation of domestic waste.
2. Only wheelbases of 4700mm and 5100mm are used, and only leaf spring suspensions are used. This vehicle can optionally be equipped with different box body appearances, and can be optionally equipped with a flip bucket device with different styles of sealing covers, a flip bucket device, a fully sealed bucket, a swing arm device, and a dump bucket device.
3. The side protection material is Q235, connected by bolts and welding. The rear protection is replaced by special devices. The ground clearance of the lower edge is 420mm.
