Product Description:
This HOWO 4x2 Cooling Reefer Truck has the following characteristics:
1. Optional single-row cab. For this option, the inner length of the cargo compartment's side panels can be optionally 5050mm, 4000mm, or 4080mm. Optional half-row cab. For this option, the inner length of the cargo compartment's side panels can be optionally 4700mm, 4100mm, or 3800mm.
2. Optional refrigeration unit with the same power. Optional front mask, optional rearview mirror, optional deflector. Optional different styles of cab appearance, optional different styles of bumper, optional different styles of rear combination lamp, and optional aluminum alloy wheels.
3. The parameter correspondence relationship of curb weight/number of occupants allowed in the cab/rated load capacity is as follows: 4700/2/5160; 4700/3/5095; 4800/2/5060; 4800/3/4995. The correspondence relationship between the overall length (mm) of the vehicle and the front overhang (mm), wheelbase (mm), and rear overhang (mm) parameters is as follows: 6995 = 1180 + 3800 + 2015; 7100 = 1180 + 3800 + 2120; 5995 = 1180 + 3280 + 1535.
4. The top of the carriage is closed and cannot be opened. The material of the side protection device is Q235A. The connection method is bolt connection. The material of the rear protection device is Q235A. The connection method is bolt connection. The cross-sectional dimension is 100mm×50mm. The ground clearance is 480mm.
Main Technical Parameters:
| Vehicle Description | Brand | CLW |
| GVW(kg) | 9990 | |
| Curb Weight(kg) | 4800 | |
| Loading Weight(kg) | 4995 | |
| Overall Dimension(mm) | 7100x2450x3445 | |
| Wheelbase(mm) | 3800 | |
| Front/Rear Overhang(mm) | 1180/2120 | |
| Approach/Departure Angle | `18/16 | |
| Axle Load(kg) | 3590/6400 | |
| Number of Cabs | 3 | |
| Top Speed(km/h) | 95 | |
| Chassis Brand | HOWO | |
| Chassis Model | ZZ1107G3815F | |
| Cabin | Single,LHD,with A/C | |
| Engine | Model | WP3NQ170E62 |
| HP | 170 | |
| Emission Standard | Euro 5 | |
| Displacement/Output(ml/kw) | 2970/125 | |
| Fuel Type | Diesel | |
| Rate Speed(rpm) | 2800 | |
| Maximum Torque(N·m) | 520 | |
| Maximum Torque Speed(rpm) | 1400-2100 | |
| Gearbox | 6Forward/1Reverse Gear | |
| Tyre | 6+1spare tire;8.25R20 14PR | |
| Van | Box Size(mm) | 5050x2300x2300 |
| Material | Fiberglass | |
| Insulating Layer | 8cm polyurethane foam | |
| Refrigerator | Brand | Coolspeed |
| Applicable Temperature | `-25~+30°C | |
| Air Volume(m³/h) | 3000 | |
| Air Speed(m/s) | 3.5 | |
| Condenser Dimensions(mm) | 1300x540x465 | |
| Evaporator Dimensions(mm) | 1376x622x253 | |
| Remarks | Part Optional:Ventilation Slot | |
| Hook | ||
| External Power Supply | ||
| Side Door | ||
Optional tailgate：
The roof of the carriage is closed and cannot be opened. The front mask, front combination lamps, front bumper can be selected according to the chassis. Mirrors and a one-and-a-half-row cab can be selected. A deflector and side doors can be selected. The side door can be a single door, double door or no door, and a built-in refrigeration unit can be selected. Insulated composite panels can be selected. Door locks can be selected as 2 bars and 2 locks or 4 bars and 4 locks.
Fuel tanks, batteries, urea tanks, and air storage cylinders can be selected for left and right installation positions according to the chassis. A hydraulic tailgate can be selected. The horizontal length of the retracted state is 290mm, and the mass of the hydraulic tailgate is 450kg. The materials of the side and rear lower protective devices are Q235 and are connected to the frame by bolts. The cross-sectional dimensions of the rear lower protective device (mm): 120×60. Ground clearance: 450mm. When a hydraulic tailgate is selected, the rear protection is three-segmented and welded to the frame. Other models of refrigeration units with equivalent power can be selected.
