Product Description:
This Foton Aumark 4x2 Cooling Reefer Truck has the following characteristics:
1. The top of the cargo compartment is closed and cannot be opened. Optional single, double or no side doors on both sides are available. Optional independent double-row doors are available. Optional rear three-opening doors are available. Optional refrigeration units with the same power are available, and the appearance and shape may vary. Optional cab enclosure styles are available. Optional side protection styles are available.
2. The connection method between the side protection and the crossbeam of the cargo box is by bolts. The material of the side protection is cold-rolled sheet B-1.5-GB/T 708. The connection method between the rear protection and the longitudinal beam of the vehicle frame is by bolts. The material of the rear lower protection device is 510L.
3. The cross-sectional dimension of the rear protection device is 120 mm × 60 mm. The height of the rear protection from the ground of the vehicle is 410 mm, 430 mm, 450 mm, 470 mm, 480 mm. Optional circular tube cold-rolled - Q235B - 6.0 for the rear protection. Connection method: bolt connection. The cross-section of the rear protection device is a diameter of 120 mm, and the height from the ground is 480 mm.
4. Optional left fuel tank. Optional hydraulic tailgate. The mass of the tailgate is 550 kg. The horizontal length of the hydraulic tailgate in the retracted state is 280 mm. Optional new front lamp styles. Optional integrated rear-view mirrors. Optional LOGO markings. Optional fuel tanks.
Main Technical Parameters:
| Vehicle Description | Brand | CLW |
| GVW(kg) | 9990 | |
| Curb Weight(kg) | 4800 | |
| Loading Weight(kg) | 4995 | |
| Overall Dimension(mm) | 7470x2370x3540 | |
| Wheelbase(mm) | 4200 | |
| Front/Rear Overhang(mm) | 1225/2370 | |
| Approach/Departure Angle | `19/10 | |
| Axle Load(kg) | 5600/10400 | |
| Number of Cabs | 3 | |
| Top Speed(km/h) | 95 | |
| Chassis Brand | FOTON | |
| Chassis Model | BJ1168VKPFG-FM | |
| Cabin | Single,LHD,with A/C | |
| Engine | Model | YCS04200-68 |
| HP | 200 | |
| Emission Standard | Euro 5 | |
| Displacement/Output(ml/kw) | 4160/147 | |
| Fuel Type | Diesel | |
| Rate Speed(rpm) | 2300 | |
| Maximum Torque(N·m) | 720 | |
| Maximum Torque Speed(rpm) | 1200-1600 | |
| Gearbox | 5Forward/1Reverse Gear | |
| Tyre | 6+1spare tire;10R22.5 16PR | |
| Van | Box Size(mm) | 5100x2200x2200 |
| Material | Fiberglass | |
| Insulating Layer | 8cm polyurethane foam | |
| Refrigerator | Brand | Hanxue |
| Applicable Temperature | `-25~+30°C | |
| Air Volume(m³/h) | 2600 | |
| Air Speed(m/s) | 3 | |
| Condenser Dimensions(mm) | 1300x540x465 | |
| Evaporator Dimensions(mm) | 1376x622x253 | |
| Remarks | Part Optional:Ventilation Slot | |
| Hook | ||
| External Power Supply | ||
| Side Door | ||
Optional tailgate：
The roof of the carriage is closed and cannot be opened. The front mask, front combination lamps, front bumper can be selected according to the chassis. Mirrors and a one-and-a-half-row cab can be selected. A deflector and side doors can be selected. The side door can be a single door, double door or no door, and a built-in refrigeration unit can be selected. Insulated composite panels can be selected. Door locks can be selected as 2 bars and 2 locks or 4 bars and 4 locks.
Fuel tanks, batteries, urea tanks, and air storage cylinders can be selected for left and right installation positions according to the chassis. A hydraulic tailgate can be selected. The horizontal length of the retracted state is 290mm, and the mass of the hydraulic tailgate is 450kg. The materials of the side and rear lower protective devices are Q235 and are connected to the frame by bolts. The cross-sectional dimensions of the rear lower protective device (mm): 120×60. Ground clearance: 450mm. When a hydraulic tailgate is selected, the rear protection is three-segmented and welded to the frame. Other models of refrigeration units with equivalent power can be selected.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
