Product Description：
1. Total tank capacity: 21.1 cubic meters. Effective tank volume: 20 cubic meters. Transport medium: water. Density: 800 kilograms per cubic meter. Tank dimensions (length × width × height) in mm: 7000×2350×1620.
2. Select a chassis with a wheelbase of 5100+1300 mm for modification.
3. The materials for side and rear protections are both Q235. The connection method for side protection is bolt connection. The connection method for rear protection is welding connection. The cross-sectional dimensions of rear protection in mm are 120×50. The ground clearance of the lower edge is 470 mm.
Main Technical Parameters
| Vehicle Description | Brand | CLW |
| GVW(kg) | 26000 | |
| Curb Weight(kg) | 11805 | |
| Loading Weight(kg) | 14065 | |
| Overall Dimension(mm) | 11000x2500x3250 | |
| Wheelbase(mm) | 5100+1300 | |
| Axle Load(kg) | 7000/18000(double) | |
| Top Speed(km/h) | 95 | |
| Chassis Brand | ISUZU | |
| Chassis Model | QL1250ULCZY | |
| Cabin | Single,LHD,with A/C | |
| Engine | Model | 6UZ1-TCG51 |
| HP | 350 | |
| Emission Standard | Euro 3 | |
| Displacement/Output(ml/kw) | 9839/279 | |
| Fuel Type | Diesel | |
| Maximum Torque(N·m) | 1422 | |
| Gearbox | 12Forward/1Reverse Gear | |
| Tyre | 315/80R22.5 | |
| Water Tank | Tank Capacity | 20000L |
| Tank Dimension(mm) | 7000x2350x1620 | |
| Tank Material | 304-2B Food grade stainless steel | |
| Thickness | 5mm | |
| Inlet/outlet valve | yes | |
| Carriage | 2 | |
| Stainless steel pump,pump in/out | ||
| Wave board | Yes | |
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
